Installing Memory 9

Removing a SIMM

To remove a SIMM, follow these steps:

1 Press the holding clips on both sides of the SIMM

outward to release it.

2 Tilt the SIMM to a 45° angle.

3 Pull the SIMM up and out of the socket.

Installing a DIMM

To install a DIMM, follow these steps:

1 Insert the DIMM vertically into the

socket. (DIMMs can fit into the slot

only one way.)

2 Push down on the DIMM to seat it,

and then raise the plastic clips at

either side to lock it in place.
